42U 600×600 mm IP Floor-Standing Server Rack with Perforated Doors, Black

42U 600×600 mm IP floor-standing server rack is a professional solution for housing server, network, telecommunications, and other electronic equipment. The cabinet features a durable knock-down construction made of 1.0–2.0 mm sheet steel and is designed for a maximum static load of up to 1000 kg.

The rack is equipped with perforated doors that promote natural airflow inside the enclosure and help dissipate heat generated by installed equipment. This is especially important when mounting servers, network switches, routers, UPS systems, and other devices with significant heat output.

Durable Knock-Down Construction

The server cabinet frame is made of sheet steel and features a fully knock-down design. This construction makes transportation, moving the cabinet into technical rooms, and on-site assembly significantly easier.

With a maximum static load capacity of 1000 kg, the rack is suitable for installing a large amount of heavy server and telecommunications equipment.

Perforated Doors for Improved Ventilation

The perforated door design allows air to circulate freely through the cabinet, helping maintain a stable operating temperature for installed equipment and improving overall ventilation efficiency.

The doors can open up to 180°, providing convenient access to equipment during installation, cabling, maintenance, and future upgrades.

Convenient Equipment Installation

The internal mounting rails can be adjusted in 25 mm increments, allowing the rack depth configuration to be adapted to the dimensions and requirements of installed equipment.

The cabinet is suitable for installing servers, network switches, routers, patch panels, cable managers, power distribution units, optical equipment, and other compatible components.

Cable Entry System

For convenient cable management, the cabinet is equipped with cable entry points located both at the top and bottom.

This design allows power, network, and fiber-optic cables to be routed from above or below, simplifying the organization of structured cabling systems and helping keep the installation neat and serviceable.

Protection and Finish

The server rack has an IP30 protection rating, providing basic protection for installed equipment against the ingress of solid foreign objects.

Metal surfaces are finished with a durable powder-polymer coating, improving wear resistance and protecting the steel during long-term operation.

The cabinet is finished in black RAL 9005, giving it a professional appearance suitable for server rooms, data centers, telecommunications facilities, and other technical environments.

Main Specifications

• Type: floor-standing server rack
• Rack height: 42U
• Dimensions: 600×600 mm
• Door type: perforated
• Construction: knock-down
• Material: sheet steel
• Steel thickness: 1.0–2.0 mm
• Maximum static load: 1000 kg
• Protection rating: IP30
• Installation type: floor-standing
• Door opening angle: 180°
• Mounting rail adjustment step: 25 mm
• Cable entries: two in the base and two in the roof
• Finish: powder-polymer coating
• Color: black
• RAL color: RAL 9005
• Country of manufacture: Ukraine
• Warranty: 12 months

Applications of the 42U 600×600 mm Server Rack

This server cabinet is suitable for building professional IT and telecommunications infrastructure in server rooms, offices, administrative buildings, data centers, industrial facilities, video surveillance systems, telecommunications nodes, structured cabling systems, local area networks, access control systems, and automation installations.

It can be used to organize servers, Ethernet switches, routers, patch panels, fiber-optic distribution equipment, cable managers, power distribution units, and other compatible network hardware.

Key Advantages of the 42U IP Server Rack

42U capacity. Provides ample space for building a complete server or telecommunications installation within a single cabinet.

Up to 1000 kg load capacity. The robust steel construction is suitable for a large amount of heavy equipment.

Perforated doors. Improve airflow through the cabinet and help remove heat generated by active network and server equipment.

Knock-down construction. Makes transportation and installation easier, especially in buildings with limited access.

Adjustable mounting rails. The 25 mm adjustment step makes it possible to configure the internal space for equipment of different depths.

Top and bottom cable entries. Simplify cable routing and organization inside the cabinet.

Powder-polymer coating. Provides a durable finish and additional protection for metal surfaces.

Frequently Asked Questions

What is the maximum load capacity of the rack?

The maximum static load capacity is up to 1000 kg.

Is this rack suitable for heavy server equipment?

Yes. Thanks to its steel construction and 1000 kg maximum static load capacity, the rack is suitable for server, network, and telecommunications equipment.

Why are perforated doors important?

Perforated doors improve airflow through the cabinet and help dissipate heat generated by servers, switches, UPS systems, and other active equipment.

Are the mounting rails adjustable?

Yes. The mounting rails can be adjusted in 25 mm increments, allowing the internal configuration to be adapted to equipment of different depths.

Where can cables enter the cabinet?

Cable entry points are provided at both the top and bottom of the rack — two in the base and two in the roof.

What is the maximum door opening angle?

The doors can open up to 180°, providing convenient access to installed equipment.

What is the protection rating?

The server rack has an IP30 protection rating.

What color is the cabinet?

The cabinet is finished in black RAL 9005 with a durable powder-polymer coating.
